Display

• Model: E8630
• Diagonal Size: (inch) 86
• Display Area: 1895.04 (H) × 1065.96 (V) mm
• Aspect Ratio: 16:9
• Resolution: 3840 (H) × 2160 (V)
• Panel Type: IPS
• Viewing Angle: 178° (H/V)
• Screen Level: A-Level
• Panel Brightness: 400 nits (typ.), 450 nits (max.)
• Contrast Ratio:  3,000:1 (typ.), 50,000:1 (dynamic)
• Color Depth: 1.07B (10bit)
• Color Gamut: (typ.) 98% sRGB
• Color Accuracy: ΔE≤1
• Glass: Zero parallax 3mm thickness 9H tempered
• Surface Technology: Anti-glare, 25% haze
• Sensor: Ambient light sensor, Ambient color temperature sensor
• Eyes Care: TÜV Flicker Free, TÜV Low Blue Light
• Refresh Rate: 60Hz
• Response Time: 8ms
• Backlight Unit: DLED
• Backlight Life: (typ.) ≥ 60,000 Hours


Connectivity

• HDMI IN × 3 : Up to 4K@60Hz, HDCP 1.4&2.2&2.3, CEC
• USB 2.0 × 1 : For system upgrades
• USB 3.0 × 4 : Front×2 + Rear×2
• Touch × 2 : 2.0 × 1, 3.0 × 1
• Input :
  • USB Type-C x 2 : Video and audio transmission, touch, charging, LAN network sharing. Front: up to 65W PD, Rear: up to 15W PD
  • DP IN × 1 : 4K@60Hz, HDCP 1.4&2.2&2.3
  • AUDIO IN × 1 :  3.5mm jack
  • VGA IN: Up to 1080P@60Hz
  • RS232 × 1 Baud rate 9600
  • RJ45 IN × 1 10M/100M/1000Mbps
  • TF Card Port × 1 Expandable up to 1TB
• Output :
  • HDMI OUT × 1 Up to 4K@60Hz
  • AUDIO OUT × 1 3.5mm jack
  • SPDIF × 1 PCM output format
  • RJ45 OUT × 1 10M/100M/1000Mbps
• OPS Slot Module slot × 1
• Wi-Fi Module Slot : Module slot × 1
• Wi-Fi Module (SI07B) : Wi-Fi 6 supported 802.11ac/b/g/n/a/ax, 2.4GHz/5GHz
• Bluetooth : 5.2


Touch System

• Touch Technology : Infrared recognition
• Touch Point : 40 Points touch
• Object Recognition Range : 3 mm
• Accuracy :  ± 1.5 mm
• Response Time : ≤ 5 ms
• Writing Height : ≤ 2 mm
• MAXHUB Think&Ink : YES
• System (Touch Return) : Windows11/Windows10/Windows8/Windows7/ Android/Linux/Mac OS X/Chrome


Built-in System

• Operating System : Android 14.0
• Certification : Google EDLA certification
• RAM : 8 GB
• ROM : 2128 GB
• SoC Process : 8 nm
• CPU : A72×4+A53×4 octa-core, 2.2GHz
• GPU : Mali G52 MC3
• NPU : 6 TOPS


Audio

• Audio System : SkyWave Sound System
• Sound Channel : 2.2
• Speaker Power : 2×8W+2×18W (output), 2×12W+2×25W (maximum)
• Sound Pressure Level : 88 dB (1W, 1m)


Physical Specification

• Dimension (L×H×D) : 1959×1179×100 mm
• Shipping Dimension (L×H×D) : 2110×1305×225 mm
• Thickness of Machine and Wall Mount : 129 mm (WIB9060H)
• Wall-hanging Screw : M4×14 mm
• VESA : No
• Net Weight : 52.45 kg
• Gross Weight : 69.00 kg

Garansi : 3 Tahun
