MAXHUB U7540

IFP (Interactive Flat Panel)

Available At:

MAXHUB U7540 adalah solusi serbaguna untuk kebutuhan pendidikan dan diskusi kolaboratif. Dilengkapi dengan sistem operasi bersertifikasi Google EDLA, perangkat ini memastikan integrasi yang mulus dengan aplikasi dan akun Google, sementara SoC yang didukung AI menjamin kinerja yang lancar. Layar sentuh canggihnya memungkinkan penulisan yang presisi, dan kamera serta mikrofon AI yang mumpuni menghasilkan audio dan video yang jernih untuk interaksi yang lancar. Dengan opsi konektivitas yang serbaguna, perangkat ini memudahkan berbagi konten dan meningkatkan kolaborasi, menjadikannya alat yang ideal untuk komunikasi yang produktif dan menarik.

Summary

Display:

  • Model: U7540
  • Diagonal Size: (inch) 75
  • Display Area: 1650.24 (H) × 928.26 (V) mm
  • Aspect Ratio: 16:9
  • Resolution: 3840 (H) × 2160 (V)
  • Viewing Angle: 178° (H/V)
  • Screen Level: A-Level
  • Panel Brightness: 500 nits (max.)
  • Contrast Ratio:  5,000:1 (typ.), 50,000:1 (dynamic)
  • Color Depth: 1.07B (10bit)
  • Color Gamut: (typ.) 98% sRGB
  • Color Accuracy: ΔE≤1
  • Glass: Zero parallax 3mm thickness 9H tempered
  • Surface Technology: Non-glare, 25% haze Etched-AG Technology
  • Sensor: Ambient light sensor Ambient color temperature sensor
  • Eyes Care: TÜV Flicker Free TÜV Low Blue Light
  • Refresh Rate: 60Hz
  • Response Time: 6.5ms
  • Backlight Unit: DLED
  • Backlight Life: (typ.) ≥ 60,000 Hours



Connectivity:

  • HDMI IN × 4 : Up to 4K@60Hz, HDCP 1.4&2.2&2.3, CEC, ARC (HDMI 1)
  • USB 2.0 × 1 : For system upgrades
  • USB 3.0 × 4 : Front×2 + Rear×2
  • Touch × 2 : 3.0×2

Video and audio transmission, touch, charging,

Input :

  • USB Type-C x 2 : LAN network sharing. Front: up to 65W PD; Rear: up to 100W PD
  • DP IN × 1 : 4K@30Hz, HDCP 1.4&2.2&2.3
  • AUDIO IN × 1 :  3.5mm jack
  • RS232 × 1 Baud rate 9600
  • RJ45 IN × 1 10M/100M/1000Mbps
  • TF Card Port × 1 Expandable up to 1TB
  • HDMI OUT × 1 Up to 4K@60Hz
  • AUDIO OUT × 1 3.5mm jack



Output :

  • USB Type-C × 1 Type-C OUT
  • SPDIF × 1 PCM output format
  • RJ45 OUT × 1 10M/100M/1000Mbps

OPS Slot :  Module slot × 1

Wi-Fi Module Slot : Module slot × 1

Wi-Fi Module (SI07B) : Wi-Fi 6 supported 802.11ac/b/g/n/a/ax, 2.4GHz/5GHz

Bluetooth : 5.2

Touch System

  • Touch Technology : Infrared recognition
  • Touch Point : 50 Points touch
  • Object Recognition Range : 1.5 mm
  • Accuracy :  ± 0.5 mm
  • Response Time : ≤ 2.5 ms
  • Writing Height : ≤ 1 mm
  • MAXHUB Think&Ink : Direct Annotation / Palm Rejection / Sharp Erase / Erase and Write Simultaneously / Multi-level Object Recognition / Single Pen Dual Color
  • System (Touch Return) : Windows11/Windows10/Windows8/Windows7/ Android/Linux/Mac OS X/Chrome



Built-in System

  • Operating System : Android 15.0
  • Certification : Google EDLA certification
  • RAM : 16 GB
  • ROM : 256 GB
  • SoC Process : 8 nm
  • CPU : A76×4+A55×4 Octa-core, 2.4GHz
  • GPU : Mali-G610 MP4
  • NPU : 6 TOPS



Camera

  • Quantity : × 1
  • Resolution : 50MP
  • FOV : 115° DFOV, 101° HFOV, 85° VFOV, Manual Mode, Auto Framing
  • Feature :  Speaker Tracking, Person Counting, Random Election



Audio

  • Audio System : SkyWave Sound System
  • Sound Channel : 2.2
  • Speaker Power : 2×8W+2×18W (output), 2×12W+2×25W (maximum)
  • Sound Pressure Level : 88 dB (1W, 1m)



Microphone

  • Quantity : 8-mic array
  • Pick-up : Angle 180°
  • Pick-up Range : 0~12 m, Intelligent Audio Fence, AI Spatial Sound
  • Feature : AEC (Auto Echo Cancellation), ANC (AI Noise Cancellation), AGC (Auto Gain Control)



Physical Specification

  • Dimension (L×H×D) : 1709.4 × 1034 × 97 mm
  • Shipping Dimension (L×H×D) : 1863 × 1148 × 185 mm
  • Thickness of Machine and Wall Mount : 122 mm
  • Wall-hanging Screw : M7×56 mm
  • VESA : No
  • Net Weight : 40.6 kg
  • Gross Weight : 53.5 kg



Garansi : 3 Tahun

Product Description

Order Now
